Aprašymas

"Poynting A-MIMO-0004-V1-19-B. Antenna gain level (max): 21 dBi, Frequency band: 0.617 - 7.2 GHz, Impedance: 50 Ω. Antenna type: Omni-directional antenna, Antenna connector type: SMA, Connector gender: Male. Input voltage: 2.7 - 3.3 V. Compliance certificates: CE, RoHS. Diameter: 16 cm"\n"The MIMO-4-19 is a high-performance 9-in-1 multi-frequency antenna housed in a single enclosure, providing four cellular MIMO antennas, four dual-band Wi-Fi antennas, and a GPS/GLONASS antenna. Designed for LTE/4G and emerging 5G networks, it supports a wide frequency range from 617 MHz to 6000 MHz, ensuring seamless connectivity across multiple operators and future cellular technologies up to 6 GHz.

Ultra-Wideband Cellular Coverage:Supports frequencies from 617 MHz to 6 GHz, covering LTE and 5G applications.
Advanced 4x4 Cellular MIMO Technology: Enhances signal strength, pattern diversity, and omnidirectional coverage.
High-Performance 4x4 MIMO Wi-Fi Antennas: Supports concurrent 2.4 GHz and 5–7.2 GHz operation for superior wireless performance.
Integrated GPS/GLONASS Antenna: High-performance active GPS system for precise positioning and navigation.
Optimised for Transportation & Marine Use: Designed to meet the demanding requirements of commercial vehicles, marine, and industrial applications.
Futureproof Connectivity: Ensures long-term compatibility with evolving cellular, Wi-Fi, and IoT technologies.
Superior Radiation Performance: Engineered for an optimal balance between omnidirectionality, diversity, and signal propagation.
The MIMO-4-19 is the ultimate solution for transportation, marine, M2M, and IoT applications, delivering exceptional performance, durability, and future-ready connectivity across multiple frequency bands.

Ideal Applications
Transport broadband cellular and Wi-Fi distribution, automation and telemetry for busses, utility, trucking and public safety vehicles
Industrial factory automation, robotic machinery and other M2M systems telemetry
Farming & Agricultural automation such as M2M & IoT
Broadband cellular to Wi-Fi distribution for Marine/Boats
Mining vehicles & machinery communications, telemetry, and automation (M2M & IoT)"
